PRODUCT FEATURES
- Compact: Design has an integral shallow well adapter built into the casing, which eliminates the need for a separate shallow well adapter.
Serviceable:
- Back pullout design allows disassembly of pump for service without disturbing piping.
- Two compartment motor for easy access to motor wiring and replaceable components.
- Nozzles clean out plug in pump case.
- Corrosion resistant, engineered plastic tubing and fittings are easily removed for cleaning. Premium O-ring design fittings need only be hand tight to seal.
- Impeller: F.D.A. compliant, glass filled engineered composite. Corrosion and abrasion resistant.
- Diffuser (Guidevane): Bolt down diffuser provides positive alignment with impeller. Diffuser also has stainless wear ring for extended performance in abrasive conditions. F.D.A. compliant, injection molded, food grade, glass filled engineered composite for durability and abrasion resistance.
APPLICATIONS
Specifically designed for the following uses: • Homes • Cottages • Booster service
SPECIFICATIONS Pump:
- Pipe connections: 1¼”
- NPT suction and 1” NPT discharge
- Pressure switch: AS4 preset (30-50 PSI).
- Motor: NEMA standard • 60 Hz • ½ – 1½ HP, 115/230 V capacitor start
- Single phase
- 3500 RPM
- Built-in overload with automatic reset
- Stainless steel shaft
- Rotation: clockwise when viewed from motor end
- UL778 listed
- Maximum temperature: 140ºF
