Features:

• Made of high-quality material, anti-corrosion, durable in use.
• Apply for, air, liquid and other non-corrosive media.
• Equipped with mounting bracket and screws, easy to install.
• The SPDT switch ensures reliable contact switching.
• Mainly used for high and low voltage limit control of refrigeration equipment or automatic system air conditioning equipment.

Specification:

Material: Plastic, iron plating nickel, stainless steel, brass

Weight: 381g/13.4oz

Pressure regulating range (bar): -1 (Min) ~0 ()

Differential pressure adjustment range (bar): 0.2 (Min) ~0.5 ()

Factory setting (bar): -0.2 (OFF/ON) ~ -0.6 (ON/OFF)

Maximum air tightness test (bar): 16.5

Power supply voltage: 24V~380V

Micro switch life: 100,000 times

Electrical parameters:

When the voltage is 125VAC, the non-inductive current is 20A, the full load current is 15A, and the instantaneous current is 72A.

When the voltage is 250VAC, the non-inductive current is 10A, the full load current is 8A, and the instantaneous current is 72A
